Download Catalogue12000lb (5454Kgs.) 6.6hp 12V Rope - Gen1 (ดูรายละเอียด)
Top Speed Electric Winch
12000lb 6.6hp 12V With Synthetic Rope - Gen1
รอกไฟฟ้าขนาด 12000lb (5454Kgs) 6.6hp 12V แบบเชือก - Gen1
เหมาะสำหรับติดตั้งรถกระบะ off Road หรือ รถยก
G.W. 25.60 Kgs.
Carton Size: 61 x 35 x 26 cms.
SPECIFICATION
Working Load: 12000lbs (5443kg) Single line
Motor: 4.8kw/6.6hp(12V) Series Wound
Control: Remote Switch, 12ft(3.7m) lead
Gear train: 3 Stage Planetary
Gear reduction ratio: 187.2:1
Clutch: Turn 180°
Braking Action: Two-way, Automatic In-The-Drum
Drum Dimensions: Φ2.5” x 8.8” (Φ63.5 x 224 mm)
Synthetic Rope: Φ10mm x 28m
Fairlead: Hawse Fairlead
Battery: Recommended:650CCA minimum for winching, Battery Leads: 2 gauge, 72” (1.83m)
Finish: Dark gray powder coat
Overall dimensions: (L*W*H) 21.1” x 6.3” x 8.6” (537mm x 160mm x 218mm)
Mounting Bolt Pattern: 10” x 4.5” (254 x 114.3 mm)
